ไฟเบอร์เลเซอร์ Fiber Laser : VF3015H

Features : VF3015H

• Fully enclosed with negative pressure, three fans are installed inside to ensure that dusts and wastes are ejected from vents at the bottom of the fiber laser cutting machine

• This fiber laser cutting machine can be easily loaded into shipping containers for export without dissembling protective cover thanks to its compact structure. It can be directly put into use after delivery.

• Table exchange switch and emergency stop button are located at the middle of the laser cutting machine, enabling loading and unloading to be easily accomplished.

• For easy maintenance of parts and Y-axis guide rail within the enclosure, doors are installed on either side of the fiber laser cutting machine.

• Safety measures are available in line with international standards, as evidenced by the equipping with four light curtains that emit infrared lights.

• Multiple dust collectors are installed to function in step with the negative pressure system, enabling the dust to be easily removed.

• The machine body will remain stable after ten years of use and will not deform under full acceleration of 1.2G.

Model	CMH1530-R-A
Working area	3000x1500 mm.
Overall dimension	4500x2230x2100 mm.
Laser power	1500-12000W
Weight	6500 kg
Maximum Speed	120 m/min
Positioning accuracy	±0.05/1000 mm/m
Repeated Positioning accuracy	±0.03/1000 mm/m
Software	Cypcut

ไฟเบอร์เลเซอร์ Fiber Laser : FLY SERIES

Features : FLY SERIES

• Gantry structure, high strength welding frame, stress reduction treatment, good rigidity, small deformation.

• Enclosing exterior protective design, CE standard protective safety window.

• Ergonomic design, intelligent operating terminal, friendly interface, easy to learn.

• Precision servo motor with high accuracy transmission mechanism, large transmission torque, small error, good dynamic performance.

• Y axis sliding plate is made by cast aluminum, with integrated z-axis system: high precision, fast response, stable operation.

• Double-layer translation shuƩle tables, the structure is safe and reliable, with few failures and high efficiency.

• Built in remote assistance function to deal with equipment failure, improve the time efficiency of equipment fault troubleshooting and effectively reduce the cost of after-sales service.

Model	Fly3015 / Fly4020 / Fly6020 / Fly6025 / Fly8025
Working area	3050x1550 mm. / 6000x2500 mm. / 8000x2500 mm.
Overall dimension	9000x3100x2100 mm. / 11000x3600x2100 mm. / 15500x3600x2100 mm. / 19500x4200x2100 mm.
Laser power	1500-20000W
Weight	7500 kg
Maximum Speed	140 m/min
Positioning accuracy	±0.05/1000 mm.
Repeated Positioning accuracy	±0.03/1000 mm.
Software	Cypcut

ไฟเบอร์เลเซอร์ Fiber Laser : PCH60022-A

Features : PCH6002-A

• Equipped with pneumatic self-centering chuck, which support symmetrical independent double-action clamping. Auto- clamping, no need manual intervention. Simple, stable and good sealing structure. Clamp is suitable for square, round and oval pipes, flat and triangle tube, profile etc.

• Reinforced welding machine body, with high precision and stability.

• Imported large gantry machine, with high precision processing, the internal stress is eliminated by tempering and vibration aging to ensure that the machine deformation tolerance is within 0.03mm.

• Integrated structure design, compacted layout, small size occupation.

• Enjoy high efficiency of electro-optic conversion, up to more than 30%, which can greatly save power consumption and achieve the highest production efficiency.

• Only electric needed, auxiliary gas blowing help to ensure cutting surface smoothly.

Model	PCH6002-A
Tube cutting size	Ø10x120 / Ø20x220 mm.
Maximum dust length	6000 mm.
Overall dimension	12000x2200x2300 mm.
Laser power	1500-6000W
Weight	6500 kg
Maximum Speed	120 m/min
Positioning accuracy	±0.03/1000 mm.
Repeated Positioning accuracy	±0.01/1000 mm.
Software	Cypcut

ไฟเบอร์เลเซอร์ Fiber Laser : CMH1530-R-A

Features : CMH1530-R-A

• High Rigidity Enhanced Aviation Aluminum Gantry, improve the gantry strength and rigidity and much lighter.

• Finite element analysis of gantry helps to achieve the best critical state of dynamic performance.

• Integrated structure design, reasonable overall layout.
• Rack and pinion structure, servo drive, secondary annealing treatment of high rigid welding frame with high accuracy and stability.

• Professional laser cutting software with graphic layout and sharp corner smoothing functions, fast piercing & cutting.

• Fiber laser has better Industry-leading wall-plug efficiency (around 40%), less power consumption.

• Hand controller is available, easy for operation.

Model	CMH1530-R-A
Working area	1500x3000 mm.
Tube cutting size	Ø20x220 mm. (Standard)
Overall dimension	7800x3300x1800 mm.
Laser power	1500-6000W
Weight	4500 kg
Maximum Speed	60 m/min
Positioning accuracy	±0.03/1000 mm.
Repeated Positioning accuracy	±0.02/1000 mm.
Software	Cypcut

ไฟเบอร์เลเซอร์ Fiber Laser : CMH1530-A

Features : CMH1530-A

• High Rigidity Enhanced Aviation Aluminum Gantry, improve the gantry strength and rigidity and much lighter.

• Finite element analysis of gantry helps to achieve the best critical state of dynamic performance.

• Integrated structure design, reasonable overall layout.

• Rack and pinion structure, servo drive, secondary annealing treatment of high rigid welding frame with high accuracy and stability.

• Professional laser cutting software with graphic layout and sharp corner smoothing functions, fast piercing & cutting.

• Fiber laser has better Industry-leading wall-plug efficiency (around 40%), less power consumption.

• Hand controller is available, easy for operation.

Model	CMH1530-A
Working area	1500x3000 mm.
Overall dimension	5010x2260x1900 mm.
Laser power	1500-6000W
Weight	3000 kg
Maximum Speed	80 m/min
Positioning accuracy	±0.03/1000 mm/m
Repeated Positioning accuracy	±0.02/1000 mm/m
Software	Cypcut

ไฟเบอร์เลเซอร์ Fiber Laser : VF-1530

Features : VF-1530

• Fiber line transmission, no need for adjustment of optical path.

• Precise height control to maintain stable cutting quality.

• The fiber laser cutting machine is 2-3 times quicker in cutting than other cutting machines, especially when cutting thin sheet metals, with high quality cutting results.

• Laser focus can be as small as 25 um, meaning cutting kerf can be very narrow and no deformation will be caused.

• This fiber laser cutting machine is applicable for cutting carbon steel, stainless steel, aluminum and copper.

• Applied in a wide range of industries, including sheet metal processing, digital products and advertising.

• 30% of electricity will be translated into laser energy during the cutting, which is higher than the CO₂ laser cutter (10%-15%) and diode laser cutter (less than 5%).

Model	VF-1530
Working area	3000x1500 mm.
Overall dimension	2280x4850x2300 mm.
Laser power	1500-6000W
Weight	3000 kg
Maximum Speed	80 m/min
Positioning accuracy	±0.05/1000 mm/m
Repeated Positioning accuracy	±0.03/1000 mm/m
Software	Cypcut

เครื่องไฟเบอร์เลเซอร์ Fiber Laser : HN-3015L

Features : HN-3015L

• Excellent Path Quality Smaller laser dot and high work efficiency, high quality.

• High Cutting Speed cutting speed is 2-3 times than same power CO2 laser cutting machine.

• Stable Running adopt top world import fiber lasers, stable performance, key parts can reach 100,000 hours.

• Low Cost save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption. It is only about 20%-30% of traditional CO2 laser cutting machine.

• Easy Operations fiber line transmission, no adjustment of optical path.

Model	HN-3015L
Working area	1550x3150 mm.
Overall dimension	2280x4850x2300 mm.
Laser power	1500-6000W
Weight	3000 kg
Maximum Speed	60 m/min
Positioning accuracy	±0.02/1000 mm/m
Repeated Positioning accuracy	±0.01/1000 mm/m
Software	Weihong

เครื่องไฟเบอร์เลเซอร์ Fiber Laser : FR-3015D

Features : FR-3015D

- High quality electrical software control system gives equipment higher cutting precision.

- The light crossbeam makes it work faster.

- It adopts, a rack and pinion drive system, and a professional cutting CNC system, and it is easy to operate and simple to maintain.

- The strict assembly process ensures the stable operation of the CNC laser cutting machine with high precision.

- Optical fiber laser cutting machine with imported top-grade accessories, which provides users with powerful cutting ability and efficiency.

Model	FR-3015D
Working area	1500x3100 mm.
Overall dimension	2280x4850x2300 mm.
Laser power	1500-6000W
Weight	3000 kg
Maximum Speed	80 m/min
Positioning accuracy	±0.02/1000 mm/m
Repeated Positioning accuracy	±0.01/1000 mm/m
Software	Weihong
